Denon AVC-X3800H AVR
With 9 channels of amplification, up to 4 independent subwoofers, Dolby Atmos and DTS:X, plus IMAX Enhanced and Auro-3D, the AVC-X3800H envelops larger living spaces in theatre-quality sound. Enjoy amazing 8K video quality and with HEOSÂŽ Built-in, wirelessly stream and share online music between rooms.
Optimized for high-impact audio experiences
High performance 9-channel amplifier
Discrete high-current amplifiers deliver up to 180W per channel - enough power to drive any speaker.
-
DTS HD Master, DTS:X, DTS:X Pro - Yes, Yes, No
DTS Neo:X, DTS Neural:X - No, Yes
DTS Virtual:X - Yes
IMAX Enhanced - Yes
Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music - Yes, Yes, Yes, Yes
Dolby ProLogic Ilz, Dolby Surround - No, Yes
Auro 3D - Yes
360 Reality Audio / MPEG H - Yes, Yes
Multichannel Stereo - Yes
Max. Number of Processing (Pre-Amp) Channels - 11.4
Discrete Power Amplifier - Yes
Pure Direct - Yes
Audyssey - MultEQ XT32
Audyssey Dynamic EQ, Dynamic Volume - Yes, Yes
Audyssey LFC - Yes
Dirac Live Upgradability - Yes
Compressed Audio Restorer - Yes
-
HDMI Inputs: Back, Front - 6, No
HDCP2.3 support - Yes
HDMI Outputs: Main, Zone - 2, 1
HDMI 2.1: 8K/60Hz AB, 4K/120Hz AB - Yes, Yes
HDR, HLG, Dolby Vision, HDR10+, Dynamic HDR - Yes , Yes, Yes, Yes, Yes
ALLM (Auto Low Latency Mode) Pass-through for gaming - Yes
Variable Refresh Rate, Quick Flame Transport, Quick Media Switching - Yes, Yes, No
3D Signal Pass-through - Yes
8K Signal Pass-Through, Scaling, GUI Overlay - Yes, Yes, Yes
DSD Audio Capability - Yes
Audio Return Channel (ARC), Enhanced ARC - Yes, Yes
Auto LipSync - Yes
-
HDMI In, Out - 6, 3
Multi-Room Video Out: Video, HDMI - No, Yes
Analogue In, Out - 6 / No
Phono (MM) In - Yes
Digital In: Optical, Coaxial - 2 / 2
Multi-Room Out: Analog, Digital - 1 / No
Multichannel Pre-Out - Yes (11.4)
Subwoofer Out - 4 (independent)
Speaker Terminal: Gold-Plated Screw, Regular Screw - No, Yes
Number of Speaker Terminals - 11
Speaker A / B - Assignable
Bi-amp Drive - Assignable
Multi-Room Speaker Terminal - Assignable
Front Inputs: Audio, Composite, Digital (Opt), HDMI, USB - No, No, No, No, Yes
USB Audio, Made for iPod, Made for iPhone - Yes, No, No
AM/FM Tuner - No
-
Number of Power Amps - 9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) - 105W
Power Output (6 ohm, 1kHz, 0.7% 2ch Drive) - 135W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) - 180W
System Remote Control - RC-1253
Power Consumption in W - 660W
Power Consumption No-Sound (ECO On / Off) in W - 60W/100W
Standby Consumption in W - 0.1
CEC Standby Consumption in W - 0.5
Network Standby Consumption in W - Less than 2.0
Dimensions - (W x D x H) 434 Ã 389 Ã 167
Weight in kg - 12.5
