HDA MHUB (6x6) 100A

£3,200.00

MHUB is a centralised multiroom entertainment system that neatens living areas, maximises content and subscriptions, and simplifies the control experience throughout the home. With uControl inside the latest MHUB series transforms the humble video matrix into an integrated smart home hub for managing media, music and mood with the groundbreaking uControl Smart Remote or app.

MHUB is a centralised multiroom entertainment system that neatens living areas, maximises content and subscriptions, and simplifies the control experience throughout the home. With uControl inside the latest MHUB series transforms the humble video matrix into an integrated smart home hub for managing media, music and mood with the groundbreaking uControl Smart Remote or app.

Features

  • Supports formats up to 4K@60Hz (4:4:4)

  • HDR, HDR10, HDR10+, Dolby Vision* and HLG

  • 100m range (4K), 150m range (1080p)

  • Down scaling on all outputs

  • Multi-channel digital audio support up to and including Dolby/Atmos and DTS:X

  • HDMI Output Mirrors

  • Video source or zone audio extraction modes

  • Line-level (Pre-Out) volume control

  • Adjustable output gain from -12dBu to +12dBu in 1dB steps

  • Bi-directional IR

  • Expanded IO capability (API pass through of IR and RS232 data)

  • CEC Display control***

  • Works with uControl™ Remote

  • Remotely manageable

  • 2 Year Warranty (+1 with HDA Cloud Registration)

  • MHUB44100A contains cooling fans that generate noise as it ventilates the system. If possible, avoid installing in places where this noise might be unwanted or could be amplified to an unacceptable level (e.g hollow/closed cupboards).

Specification

  • MHUB66100A - Inputs: x6 HDMI / Outputs: x6 HDBaseT, x2 HDMI (Mirror), x6 Optical, x6 3.5mm Stereo

    MHUB44100A - Inputs: x4 HDMI / Outputs: x4 HDBaseT, x1 HDMI (Mirror), x4 Optical, x4 3.5mm Stereo

  • 18Gbps

  • Up to 4K@60Hz (4:4:4) with HDR

  • RGB, YCbCr 4:4:4, YUV 4:4:4, YCbCr 4:2:2/4:2:0

  • 8-bit, 10-bit, 12-bit (1080p@60Hz)
    8-bit (4K@60Hz)
    10-bit, 12-bit (4K@60Hz YCbCr 4:2:2/4:2:0)

  • HDR10, HDR10+, Dolby Vision, HLG**

  • 1080p (150m / 492ft), 4K 100m / 394ft

  • PCM 2.0 / 5.1 / 7.1, Dolby Digital / Plus / EX, Dolby True HD, DTS, DTS-EX, DTS-96 / 24, DTS High Res, DTS-HD Master Audio, DSD

  • Optical: PCM 2.0, Dolby Digital, DTS 5.1 3.5mm Stereo: LPCM 2Ch

  • PCM 2.0 44.1 / 48 / 88.2 / 96 / 176.4 / 192KHz, 16 / 20 / 24bit

  • -12dBu — +12dBu

  • -55dB — 0dB

  • MHUB66100A -
    Chassis: 440 x 226 x 44


    MHUB44100A -
    Chassis: 372 x 165 x 36

    Display receiver - 140 x 65 x 18

  • MHUB66100A -
    Chassis: 3025, Receiver: 126


    MHUB44100A -
    Chassis: 1631, Receiver: 126
