Metamaterial Absorption Technology eliminates 99% of high-frequency distortion for pure, natural sound.
12th generation Uni-Q with MAT driver array for exceptional acoustic accuracy.
Driver Performance Optimisation for enhanced sonic performance, less distortion and reduced coloration.
Patented off-set flexible port for reduced midrange coloration with exceptional levels of depth and detail.
Specifications
Model
LS50 Meta
Design
Two-way bass reflex
Drive Units
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with Metamaterial Absorption Technology
MF/LF: 130 mm (5.25 in.) aluminium cone
Crossover Frequency
2.1 kHz
Nominal Impedance
8 Ω (min. 3.5 Ω)
Frequency Range
47 Hz - 45 kHz
Typical In-room Bass Response (-6dB)
26 Hz
Frequency Response (±3dB)
79 Hz - 28 kHz
Harmonic Distortion (90dB, 1m)
<0.4% 175 Hz - 20 kHz
<0.1% 300 Hz - 10 kHz
Maximum Output
106 dB
Amplifier Power (Recommended)
40-100 W
Sensitivity (2.83V/1m)
85dB
Weight*
7.8 kg (17.2 lbs.)
Dimensions (H x W x D) with Terminal*
302 x 200 x 280.5 mm (11.9 x 7.9 x 11.0 in.)
* Measurement per unit
