Marantz Cinema 30

ÂŖ3,500.00
Limited Availability

Marantz Cinema 30 11.4ch 8K AV Receiver

CINEMA 30 is the most refined AV Receiver Marantz has created and redefines premium home theater sound. Engineered with proprietary technology optimized from decades of rich heritage, its 11.4 channels deliver unrivaled performance and can power even large-scale home theaters with ease.

Marantz Cinema 30 11.4ch 8K AV Receiver

CINEMA 30 is the most refined AV Receiver Marantz has created and redefines premium home theater sound. Engineered with proprietary technology optimized from decades of rich heritage, its 11.4 channels deliver unrivaled performance and can power even large-scale home theaters with ease.



Timeless Yet Modern Style

Excellence is heard and seen. CINEMA 30 is meticulously crafted in Japan with authentic materials in a modern style, befitting its rich heritage and stunning performance.

No Compromise Engineering

HiFi performance technologies like HDAM SA-2, and more elevate the CINEMA 30 to performance levels seldom found in an AVR.

Sound Master Tuned & Calibrated For You

Powerful calibration and tuning tools are included, enabling you to get the best performance from your system.

Technology Leader

Seven HDMI inputs, plus digital, analogue, and phono inputs – even analogue video plus loudspeaker and pre-amp outputs – ensure connectivity to virtually any components you have.

    • Number of Powered Channels11

    • Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive)-

    • Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive)140 W

    • Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)175 W

    • Power Output (6 ohm, 1 kHz, 10% 1ch Drive)250 W

    • 70% GuaranteeYes

    • Discrete Power AmplifierYes

    • Amplifier TopologyClass A/B

    • Current Feedback Topologyyes

    • Bi-Amp Driveassignable

    • DTS - DTS HD Master, DTS:X, DTS:X Pro, DTS Neural:X, DTS Virtual:X

    • Dolby - Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround

    • Max Number of Processing (Preamp) Channels - 13.4

    • IMAX Enhanced - Yes

    • Auro 3D - Yes

    • Audyssey DSX - Yes

    • Multichannel Stereo - Yes

    • Composite In / Out - 2 / 0

    • Component In / Out - 1 / 0

    • HDMI In / Out - 7 / 3

    • Multi-Room Video Out via HDMI - 0 / 0

    • Analog In / Fixed Level Out - 3 in / 0 out

    • Phono (MM) In - Yes

    • Digital In: Optical / Coaxial - 2 / 2

    • Multi-Room Out: analog / digital - 2 / 0

    • Multichannel Preamp Out - 7.2

    • Subwoofer Out - 4 (independent)

    • 7.1 multichannel input - No

    • Number of Speaker Terminals - 13

    • Speaker A / B - assignable

    • Multi-Room Speaker Terminal - assignable

    • Front Inputs - USB-A

    • USB Audio - Yes / No / No

    • FM Tuner with RDS - Yes

    • DAB+ Tuner - No

    • Multi-Room Video Out: Video / HDMI - 7 / 3

    • analog In/out - 6 / 0

    • Multichannel Pre Out - Yes (13.4)

    • Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB - No / No / No / No / Yes

    • Total HDMI Inputs / No. Support 8K - 6 / 3

    • HDCP2.3 support - Yes

    • HDMI Outputs: Main / Zone - 2 / 1

    • Analog to HDMI Video Conversion - No

    • HDMI Upscaling - 1080P/4K to 8K

    • Audio Return Channel - ARC, eARC

    • Video Dynamic Range - HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR

    • ALLM (Auto Low Latency Mode) Pass-through for gaming - Yes

    • Variable Refresh Rate / Quick Frame Transport - Yes / Yes / No

    • HDMI Pass-Through in Standby Mode - Yes

    • CEC - Yes

    • DSD Audio over HDMI - No

    • Auto LipSync - Yes

    • HDMI Inputs: Back / Front - 7 / -

    • Video Conversion Analog -> HDMI - Yes

    • HDMI to HDMI Scaling - 1080P/4K to 8K

    • HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB - Yes / Yes

    • 8K/60Hz AB / 4K/120Hz AB Pass-through In/Out - 7 / 2 (up to 40Gbps)

    • HDMI 2.0: 3D / 4K / CEC / ARC - Yes / Yes / Yes / Yes

    • HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR - Yes / Yes / Yes / Yes / Yes

    • Variable Refresh Rate / Quick Flame Transport / Quick Media Switching - Yes / Yes / No

    • 8K signal pass-through / scaling / GUI overlay - o / o / o

    • 4K Signal Pass-Through / Scaling / GUI Overlay - o / o / o

    • DSD Audio Capability - Yes

    • Copper Plated Chassis - Yes

    • Toroidal Power Supply Transformer - Yes

    • Hyper Dynamic Amplifier Modules (HDAM) (List version) - Yes

    • Pure Direct Mode - Yes

    • Gold Plated RCA Terminals - Yes

    • Clock Jitter Reducer - Yes

    • Audyssey - MultEQ XT32

    • Audyssey Dynamic EQ / Dynamic Volume - Yes / Yes

    • Audyssey LFC - Yes

    • Dirac Live Support - Yes

    • Variable Cross Over - Yes

    • Optimized Bass Redirection - Yes

    • Bass Sync - Yes

    • Dirac Live Upgradability - Yes

    • Lossy Formats - MP3 / WMA / AAC

    • Lossless formats - FLAC HD 192/24 / WAV 192/24 / ALAC 192/31

    • DSD Audio - 2.8 MHz / 5.6 MHz

    • Gapless Playback - FLAC, WAV ,ALAC ,DSD

    • Compressed Audio Enhancer: MDAX2 - Yes

    • Network Audio Sharing - Yes

    • HEOS Multi-room and Streaming - Yes

    • AirPlay Audio Streaming - AirPlay2

    • Internet Radio - TuneIn

    • Spotify* - Spotify Connect

    • Pandora - No

    • SiriusXM - Yes

    • Other Streaming Services * - Amazon Music HD/
      Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix

    • Roon tested - Yes

    • Ethernet Ports - Yes

    • Wi-Fi (include version / band) - Yes

    • Bluetooth (Include version) - Yes

    • Bluetooth Re-transmit for Bluetooth headphones - Yes

    • Voice Assistant Compatibility - Alexa / Google Voice Assistant / Apple HomePod

    • App for Smart Phones & Tablets (iOS & Android) - Marantz AVR App

    • HEOS Multi-Room Integrated - Yes

    • HEOS Link Compatibility: IR/ IP - Yes /Yes

    • Multi-Room zones - 2

    • Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog - 2 Ch / 2 Ch / Yes / Yes

    • Zone Audio Output: Speaker / Preout - Yes / Yes

    • Zone HDMI Output from HDMI Source - Yes

    • Control Connectivity - IP Control / RS232 Control / Web Control / App Control

    • IR Flasher In - Yes

    • Marantz Remote Bus - Yes

    • DC Trigger Output - 3

    • HDMI Diagnostics - Yes

    • Front Display - 2 line FLD + port hole OLED

    • GUI Languages - 3

    • Setup Assistant - Yes

    • Smart Select on Remote - Yes

    • Firmware Update by Network / USB - Yes / Yes

    • ECO Mode - Yes

    • Auto Power off - Yes

    • Sleep Timer - Yes

    • GUI Overlay on HDMI

    • CEC - Yes

    • Auto Speaker Setup by Microphone - Audyssey MultEQ XT32Dirac Live (upgrade)

    • Graphic User Interface GUI - Modern HD GUIModern HD GUI

    • Smart Select - Yes

    • Metal Front Panel - Yes

    • System Remote Control - RC-051SR

    • Power Consumption in W - 780

    • Power Consumption No-Sound (ECO on/off) in W - 65 W / 110 W

    • Standby Consumption in W - 0.2

    • CEC Standby Consumption in W - 0.5

    • Network Standby Consumption in W - Less than 2.0

    • Maximum Dimensions
      Antenna:Horizontal:(W x D x H) in mm - 442×457×189
      Antenna:Vertical :(W x D x H) in mm - 442×457×257
      W/o Antenna:(W x D x H) in mm - 442×447×189

    • Weight in kg - 8.7

    • What's in the box - Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antennas, AC cord

    • Weight in lbs. - 42.8

    • Maximum Dimensions
      Antenna:Horizontal:(W x D x H) in mm - 17.4×18.0×7.5
      Antenna:Vertical :(W x D x H) in mm - 17.4×18.0×10.2
      W/o Antenna:(W x D x H) in mm - 17.4×17.6×7.5

    • Pre-Programmed / Learnable / LCD Display - Yes / Yes / Yes
