Monitor Audio - C3L In-Ceiling Speaker

£750.00

This high-performance, large Tier 3 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where pristine sound quality is desired. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.

Price is for a Single Unit

This high-performance, large Tier 3 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where pristine sound quality is desired. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.

Price is for a Single Unit

British High-Fidelity Architectural Sound Redefined

This high-performance, large Tier 3 in-ceiling loudspeaker is designed to deliver pristine, engaging acoustics where pristine sound quality is desired. It is a three-way model featuring the very latest acoustic technologies from Monitor Audio.

This really is the last word in installed performance, featuring an RDT III bass driver, IDC II midrange driver, and IDC II tweeter with UD Waveguide II. This high-end combination ensures levels of acoustic transparency and detail found in Monitor Audio’s premium loudspeaker ranges, where much of his acoustic technology was developed. It has a cutout diameter of 212 mm and uses the patented Quik-Link speaker cable connector, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable, and strong fitment.

Monitor Audio C3L discrete in ceiling speaker

Features at a glance:
Ideal for installations where high-performance acoustics are desired  | Three-way design  |  Mid-frequency ‘mid-pod array’  |  1 x 1" IDC II tweeter with UD Waveguide II for lifelike sound  |  1 x 9" RDT III bass driver  |  1 x 4" IDC II midrange driver  |  Patented Quik-Link speaker cable connector for quicker installation  |  Tri-Grip II for easy and secure fitment

Monitor Audio C1L Black Grille

  • System Format

    3–Way

    Channels

    1

    Frequency Response, Installed (-6dB)

    45 Hz – 35 kHz​

    Nominal Impedance

    6 ohm

    Minimum Impedance (20Hz to 20kHz)

    4.8 Ohm @ 2 kHz

    Sensitivity (2.83Vrms@1m, Installed)

    89 dB

    Maximum Peak SPL* (single speaker @ 1m Z-Weighted)

    119 dB

    Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor)

    150 W

    Recommended Amplifier Power (RMS into 8 OHM, Music Signal)

    60 – 225 W

    Drive Unit Complement

    1 x 9" (229 mm) RDT III bass driver
    1 x 4" (102 mm) IDC II midrange driver
    1 x 1" (25 mm) IDC II tweeter

    Crossover Frequency

    LF/MF: 700 Hz
    MF/HF: 3.5 kHz

    Mounting Depth

    157 mm (63/16")

    Cut-Out Hole Diameter

    248 mm (93/4")

    External Dimensions (Including Grille (H x W x D))

    278 x 278 x 161​ mm (1015/16 x 1015/16 x 65/16")

    Weight (each)

    5 kg (11 lb)

    Pre-Construction Bracket

    CL-B

    Cabinet Finish

    Matte black & Orange​ & Green

    Sold As

    Single Unit with CL-Round Grille (white)

    Corner Switch

    On/Off

    HF Switch

    - /0/ +

    MF Switch

    - /0/ +

    Warranty

    Lifetime
